CO₂ Insufflator Advanced (30L)

The latest technology and the easy operation have come to move the new Co₂ Insufflators into the top class of the newest generation. The ergonomic designed & logically arranged displays inform the user about all relevant values of the insufflations at any time.

*Also available in 40L & 50L

SALIENT FEATURES

• Veress/trocar mode

• Separate digital display for actual value and set value of pressure and flow rate

• Pumped gas volume counter with Reset button

• Display for actual gas consumption & temperature

• Outlet gas temp with heater on indicator

• Co₂ Air mode button for emergency

• Co₂ gas status indicator

PRODUCT FEATURES

• High pressure Co₂ from the main cylinder can be connected direct to the insufflator.

• Micro controller based closed loop technology ensures precise control of pressure/flow parameters.

• Electronic memory retains last set values of pressure, flow rate and pumped gas volume.

• Inbuilt gas warmer provides warm Co₂ at trocar minimizing fogging and all disadvantages of chilled gas entering abdomen.

• Intermediate gas flow controller ensures stable abdominal distention during surgery.

• Functional and user-friendly design.

• Various safety features & meets quality standards.

• Rapid delivery of gas & provide immediate response for all procedures.

• Advance high speed microcontroller technology allow greater accuracy & measurement of Co₂

• Over pressure alarm & pressure release systems help assure patient safety.


PERFORMANCE FEATURES

SOFTWARE

• Software controlled technology to initiate calibration of pressure and flow of system when insufflator is turn on

• Software controlled pressure release mechanism to prevents excess pressure build up in abdomen

INBUILT GAS WARMER

• Ambygo Co₂ insufflator has unique heating systems that provides a constant temperature for the Co₂ to reduce chill effect of high flow insufflation & lenses telescope fogging

ADVANCE FLOW CONTROL

• Ambygo Co₂ insufflator is highly adaptable advance flow control insufflation for precise and safe gas flow to meet patient requirement

• Better precision for measurement of volume & flow of Co₂

• Ambygo Co₂ has pressure range from 4 to 30 mm Hg

SAFETY

• Special feature that assures a constant pressure of the Co₂

• If actual pressure is more than set pressure, the system offers a rapid & instantaneous release over

TECHNICAL SPECIFICATIONS

PNEUMATICS

• Gas : C02 supply

• CO2 gas supply systems : UNF 7/16"

• Input pressure Min. to Max. : 2 to 3 BAR

• Insufflation pressure Min. to Max. : 4-30mm H (to an accuracy of 1 mm Hg)

• Flow rate Min to Max. : 1 to 30 Ltrs/Min

• Internal over pressure release valve

• Output connection - 6 to 7 mm ID tube

INTERFACE

• 7 Segment display showing set & actual pressure, set & actual flow for temperature & Gas consumption

• Keyboard - feather touch

POWER SUPPLIES

• Power supply : 110V/230VAC + 15% @ 50-60 Hz

• Protection by fuse : 5A

• Power consumption : 125W Max with warmer else, 20W Max

MECHANICS

• Enclosure : ABS plastic box

• Dimensions (L x W x H) : 260 mm x 290 mm x 105 mm

• Weight : Approx. 2 kg
